Dimensional Diagrams HyperVac Pumps
| HyperVac 400 / 600 Dimensions | |||||
| Dims in Inches and mm | |||||
| Callout | Feature | Model 400 | Model 600 | ||
| B | Width | 9 | 229 | 9 | 229 |
| C | Height | 11 | 280 | 11 | 280 |
| N | Length | 22 | 559 | 24 | 610 |
| HyperVac 1000 / 1500 Dimensions | |||||
| Dims in Inches and mm | |||||
| Callout | Feature | Model 1000 | Model 1500 | ||
| B | Width | 11 | 280 | 11 | 280 |
| C | Height | 16 | 407 | 16 | 407 |
| N | Length | 27 | 686 | 30 | 762 |
11/10/2005
